Compatible Raspberry Pi CSI Camera Module 5MP with OV5647 and CSI Cable

Information about this module is generated with the help of AI. The description may be incomplete, inaccurate, or subject to change.
This compatible Raspberry Pi CSI Camera Module is a 5 MP camera featuring the OmniVision OV5647 CMOS image sensor. It is designed to work with Raspberry Pi computers and connects directly through the MIPI CSI interface, providing high data transfer speed and low processor overhead compared to USB cameras.

The camera is suitable for robotics, AI applications, machine vision, surveillance, time lapse photography, image capture, video recording and IoT projects. Its fixed focus lens delivers sharp images from approximately 1 meter to infinity, while the wide field of view makes it suitable for a wide range of applications.

The module captures still images at a maximum resolution of 2592 x 1944 pixels, equivalent to 5 megapixels. It supports Full HD video recording at 1920 x 1080 at 30 frames per second and VGA video at up to 90 frames per second. Video supports H.264 AVC encoding for efficient storage and streaming.

The camera is compatible with Raspberry Pi 1, Raspberry Pi 2, Raspberry Pi 3, Raspberry Pi 4, Raspberry Pi Zero, Raspberry Pi Zero W, Raspberry Pi Zero 2 W, Raspberry Pi 400 and Raspberry Pi 5. Raspberry Pi Zero models and Raspberry Pi 5 use a 22 pin CSI connector and require a 22 pin to 15 pin adapter cable when using the included 15 pin cable.

This is a compatible camera module and not an original Raspberry Pi Camera Module. It provides equivalent functionality and is a cost effective solution for many Raspberry Pi projects.

The camera is not compatible with the Raspberry Pi Pico series because those boards do not include a MIPI CSI camera interface.

Facts.
Product type: Compatible Raspberry Pi CSI Camera Module
Version: Rev 1.3 compatible
Sensor: OmniVision OV5647
Sensor type: Color CMOS
Resolution: 5 megapixels
Maximum still image resolution: 2592 x 1944 pixels
Sensor format: 1 4 inch
Sensor size: 3.67 x 2.74 mm
Pixel size: 1.4 x 1.4 um
Lens: 3.6 mm
Aperture: F2.9
Viewing angle: 54 x 41 degrees
Diagonal field of view: 72.4 degrees
Field of view at 2 m: Approximately 2.0 x 1.33 m
35 mm equivalent focal length: 35 mm
Focus: Fixed focus from approximately 1 m to infinity
Video resolution: 1920 x 1080 at 30 fps
Video: VGA up to 90 fps
Video codec: H.264 AVC
Interface: MIPI CSI
Connector: 15 pin CSI connector
Flex cable: 15 cm included
15 pin to 22 pin adapter cable: Not included
Board size: 25 x 24 mm
Compatibility: Raspberry Pi 1, Raspberry Pi 2, Raspberry Pi 3, Raspberry Pi 4, Raspberry Pi Zero, Raspberry Pi Zero W, Raspberry Pi Zero 2 W, Raspberry Pi 400 and Raspberry Pi 5
Adapter required: Raspberry Pi Zero series and Raspberry Pi 5 require a 22 pin to 15 pin adapter cable
Not compatible with: Raspberry Pi Pico, Raspberry Pi Pico W, Raspberry Pi Pico 2 and Raspberry Pi Pico 2 W
Original product: No, compatible camera module

Included.
1 pc module.

About the product.
Weight: approx 15 gram.
